GP348 Placer/Spreader Slipform Paver. From gomaco.com site.

Dmitriy Mikhailov GP348 Placer/Spreader Slipform Paver • The GP348 is a high-production placer/spreader up to 36 feet (11 m) wide with a 48 inch (1219 mm) belt and a top-of-the-line four-track GP3 for slipform paving up to 30 feet (9.1 m) wide. • The undermounted conveyor belt, located between the GP348’s tracks, folds up to allow trucks to pass by on the haul road. • Four tracks allows faster and easier job-site mobility and allows the placer/spreader to get into minimum clearance job-site conditions. • Easy transport. Only one semi-tractor trailer is needed to haul the GP348. • The GP348 is equipped with one conveyor and two auger drive circuits for placing and optional vibrator circuits for paving. • Quickly and efficiently interfaces with stringline or 3D machine guidance systems. • Powered by a Caterpillar C7.1 Tier 4 diesel engine with 302 horsepower (225 kW) allowing the GP348 to efficiently drive the conveyor belt and distribute concrete across the grade. • The strike-off features independent vertical adjustment to control the placed concrete depth without raising and lowering the prime mover. • An optional sonic sensor system can be added to the GP348 to monitor the concrete depth it is placing. Information from the sonic sensors is utilized by the G+® control system on the paver using Machine to Machine (M2M) communication to provide the optimum and consistent head of concrete in front of the paver. • The GOMACO strike-off features a Power Transition Adjuster...
