How To Remove Center Console Trim on Volvo XC60 | Removing headunit stereo from XC60

How to disassemble the Volvo XC60 center console. Start by disassembling the cover here, prying off the edges. Then you can easily take it off There are 6 snaps on the board There are two screws here We just need to unscrew these two screws One screw on each side After removing the screw We used this spudger to pry open the CD control panel below Pry it out slowly After prying open you can unplug this There are two snaps here Then we remove the screws below Let's remove it in the middle of silver iron You can feel the screw with your hand and slowly remove it Be careful when removing the screw, don't let it fall off After removing this screw We can pull the screen out like this from top to bottom, the screen can then be removed. There are two plugs behind the display, There are 2 plugs here. This is probably the way to disassemble the central control of the XC60. The above operations can be used as a reference. ---------------------------------------------------------------------------------------------------------------------- For know more about carplay adapter for FOLLOW⬇️: #volvoxc60
