Audi A4 B9 (8W) MMI MHS2 hidden green menu (GEM)

Аватар автора
Ударят Жестью
How to enter hidden green engineering menu in A4 B9 (8W) with MMI MIB2 High Scale. This mode gives access to advanced features and diagnostic data, many of which can be very useful when repairing the unit, patching the firmware, converting the vehicle to a different region, and retrofitting additional equipment. ℹ️ Turn the ignition on, wait for the Audi MMI system to start. Push buttons NAV/MAP and RADIO forwards, keep them in this position for about 3 seconds, and wait for the green hidden menu (GEM) to appear on the display. Release buttons when Engineering is visible. ⚠️ Hidden menus contain advanced options. Many of those are potentially dangerous. Using them randomly can cause main unit damage and will require advanced recovery. ℹ️ Hidden green menu requires developer mode to be enabled first. You can use OBDeleven, VCDS, VCP, or other diagnostic interface to do it. ? Enabling developer mode Module: 5F → diagnostic session → development mode Module: 5F → Adaptation → Developer mode → activated Reboot the unit ? This tutorial was made in Audi A4 B9 (8W) with MMI MHS2 system (Delphi MIB2 High Scale), but the same procedure might apply to other Audi cars with the same or similar control panel. 0:00 Audi A4 B9 (8W) 0:07 MMI MHS2 (Delphi MIB2 High Scale) 0:25 Enable green menu with OBDeleven 1:20 Audi MMI reboot 1:50 Entering GEM (Green Engineering Menu) 2:20 Exit hidden menu
