IFC Export in AutoCAD Civil 3D

FC is short for International Foundation Class and files using the IFC file format are Building Information Modelling (BIM) files. Click Export IFC Find. Alternatively, on the command line, enter ifcexport. In the Export to IFC dialog box, click Options. In the IFC Export Options dialog box, on the Header tab, select the schema version to use and enter necessary information. Drawing coordinate systems can be exported using schema version 4 or 4x1. If a drawing is assigned a coordinate system, the information is automatically included in the IFC export. When the IFC file is imported, the main drawing that is created is assigned the coordinate system found in the imported IFC file. Autodesk Civil 3D alignments and their associated finished ground profile data can be exported using schema version 4x1. Note: For each alignment, a single finished ground profile is exported. The name of the drawing active on your screen is displayed on the Header tab of the IFC Export Options dialog box. You can add information about the drawing file to be exported, such as a description of the drawing, the author and company name, authorization data, and the geographic location. This information is displayed in the header of the IFC file when the file is viewed. Other data is exported with the drawing by default and includes the name of the source drawing file and the name and version of the application in which it was created. Click the Objects tab and select the objects to be included in...
