Arduino загрузить sketch В ATmega. USB To RS232 TTL PL2303HX Converter Adapter

1. скачиваем устанавливаем драйвера 2. кликаем на кнопку загрузить sketch. как только загорается синий светодиод, сразу жмём на кнопку и отпускаем once the blue LED shines, just press the button and release USB To RS232 TTL PL2303HX Auto Converter Module Converter Adapter For arduino PL2303 Windows Driver Download PL2303_Prolific_DriverInstaller_v1.8.0.zip Как прошить ATmega328 с помощью Arduino Uno sketch Самый дешевый Arduino Uno 5$ Minimal Atmega328 without Arduino Board Как загрузить sketch к Arduino UNO чипе PL2303 использованием USB Для RS-232 Конвертер How to upload sketches to Arduino UNO chip using PL2303 USB To RS-232 Converter both can be used with gigino board, too. The manual Way Manual Reset (Press Switch Reset) 1. Connect the circuit as shown in figure. 2. Install driver for USB TO RS232 and check the number of comport. 3. At Arduino IDE software : Tools--Board-- Arduino UNO : Tools-- Serial Port -- Com X (number on your PC) 4. Click "Verify button" wait until &compiling& 5. When you need to upload sketch. Press Swith reset and hold it, Click "Upload button" and count x seconds (the time up on windows and PC you use, for my testing with XP windows took 3 seconds). After that, Release Switch. If you choose the good time for your system, you will see " Done uploading". Yor are done!!! If you quickly or slowly release switch, it cannot upload, you need to try again with the best time for you. The Automatic Way...
