KiCAD Simulation: Measuring Current Can Be Tricky

When using a .ac sweep, KiCAD won&let you directly plot current magnitude and phase, but you can add a current-sense resistor to do it for you. This video goes through the AC simulation of a simple series RL circuit and shows the tricks that you need to do to get KiCAD to measure current as well as a voltage difference between two nodes. SPICE can do these things directly, but KiCAD simulation is still a bit limited. The circuit analyzed here is a simple RL circuit and the example was taken from this online, open-source textbook:
