Comprehensive solution for non-waste processing of reinforced concrete constructions and scrap

Аватар автора
НПП ОПК. Фонтанная арматура устья скважин
R&P ENTERPRISE «OPK» offers a unique technology for the processing of large-size concrete constructions through DSK-MPR-1500 allows recycling of bulky parts of concrete and reinforced concrete products, pieces of brickwork, ceramic-granite, tiles, ceramics and other materials without preshredding. The technological line includes a complex of assemblies and mechanisms for preliminary recycling of the dismantled production defects manufacturing products, of plants reinforced concrete products as well as construction waste, etc. with subsequent automatic separation of reinforcing bars and metal inclusions, crushing and sorting in order to obtain secondary crushed stone of the necessary fractions. Reinforced concrete products and construction waste with a size of up to 12,000x1,500x600 mm (lengthwidth-thickness) are transported for recycling. Downstream the MPR-1500 recycling complex, there the following fractions of the classified ready-building material(crushed stone): 0–5 mm, 5–20 mm, 20–40 mm, 40–70 mm; reinforcing wires/barsfit for scrap.The performance of MPR-1500 is up to 130 ton/h, the power consumption of the complex-up to 310 kW. Crusher MPR-1500 is the central element of recycling complexes for reinforced concrete waste. It is loaded with overall products made of strong concrete: support of the contact network, power lines, sleepers, road and paving slabs, curbs.
