Replace the Display Panel Assembly | HP Elite x2 G4 Tablet with Keyboard | HP

Learn how to replace the display panel assembly for HP Elite x2 G4 Tablet with Keyboard. Follow these steps to replace the display panel assembly for HP Elite x2 G4 Tablet with Keyboard: - Removal - - Open the kickstand. - Remove the four 3 mm T5 Torx-head screws that secure the display panel assembly to the display enclosure. - Close the kickstand and turn the tablet over. - Using a suction cup, carefully detach the display panel assembly clips from the display enclosure in the following order: - Top-right corner - Top-left corner - Bottom-right corner - Bottom-left corner - Slowly lift the display panel assembly until you have access to the battery connector on the motherboard (approximately 90 degrees). - IMPORTANT: Lifting the panel too far may result in prematurely disconnecting the touch panel cable from the motherboard and damage to the cable and/or connector. - While supporting the display panel assembly, disconnect the battery cable from its connector on the SIM card board. - Remove the tape that covers the touchscreen and display panel ZIF connectors. - Using minimal force, lift the locking bar up on the touchscreen ZIF connector and disconnect the touchscreen ribbon cable from the motherboard. - Using minimal force, lift the locking bar up on the display panel cable ZIF connector and disconnect the display panel ribbon cable from the mother board. - Remove the display panel assembly. - Reverse this procedure to install the display panel assembly. Caution...
