TMC2209 development board | Arduino Stepper Motor Shield

I designed this TMC2209 development board to test all features with an Arduino UNO/MEGA. All pins of the TMC are connected to DIOs on the Arduino and can be used to test its features. An example script is attached in the GitHub repo. The board can be ordered on JLCPCB with assembly and costs around 50-60€ assembled and shipped (5pcs). (No Affiliation) If you want to support my work and projects, please check out my Amazon wish list! #jlcpcb
