ANENG 616 CATII600V,6000 COUNTS,TRUE RMS ,SMART PHONE TYPE MULTIMETER.MADE IN CHINA.

ANENG 616 CATII 600V,true rms 6000 counts,multimeter size 137.4x68.4x14.8mm weight 105g not include the battery TEST pen CATII 1000V,10A,82CM LONG PVC CABLE,2MM PLUG DCV 0.1mV to 600v auto 1 to 600V ±1..5%+10/±1.0%+5/±1.2%+5 ACV 0.1mV to 600v auto 1 to 600V ±1..5%+10/±1.2%+5/±1.5%+8 resistor 0.1 ohm to 60Mohm ±1.3%+5/±1.0%+5/±1.5%+10 ACA 0.1mA to 10A ±1.8%+5/±2%+8/±2.5%+8 DCA 0.1mA to 10A ±1.5%+5/±1.8%+8/±2.2%+8 capacitor 1pF to 60mF ±3%+5/±3.5%+5/±5%+6 /±10%+8 continuity lessthan 50 ohm may be beep SOUND on FREQUENCY 0.1HZ to 10 Mhz ±1.5%+5/±3%+5/±4%+10 Temperature 0 to 1000 degree C ±1%+3 DIODE yes continuity yes ncv yes Flashlight yes backlight yes apo(auto power off ) yes 15minute hold yes made in china. (eyesight data record may be error). Board XT-910-V1 20220704 FUSE SMD TYPE 10A SHUNT RESISTOR R010 CRYSTAL 8.000 LCD DRIVER HOLETK HT1621B AGTY2108HG RLY AXICOM IM41 3vdc 0634H PtC MZ3 R 100 Q 2TY 2PCS Q J3Y 2PCS R 103 6PCS R 01B Q J3 R 01B R 515 Q J3 R 106 R 101 R 103 R 103 R 100 Q 2T1 R 103 Q J3 R 100 R 104 Q J3 Q J3 R 103 Q Y1 2PCS R 106 R 226 R 01B R 101 4PCS LIST PARTS POSITION VIA THE VIDEO PHOTO . THX FOR WATCHING.
