ANSYS Meshing | Meshing For an Airfoil Simulation

Аватар автора
Разработка решений
Meshing is the process in which the continuous geometric space of an object is broken down into thousands or more shapes to define the object&physical shape properly. The more detailed a mesh is, the more accurate the 3D CAD model, allowing for high fidelity simulations. Meshing in an airfoil is a bit complex process because of curvature. In this uploaded video, I divide the geometry into two faces through the Face spilled option, which is available in the geometry section in ANSYS. Now in the process of Meshing, I cannot mesh through the edge divisions over an airfoil edge(airfoil curve) do not know why. I just applied the elements sizing in the circle on which I applied the Face split feature.
