SIGLENT SDS2000 series includes the below models: 4-channels: 2 channels: This series includes 8 models featuring 2 and 4 channels with a bandwidth from 70 to 300 MHz. General characteristics: Sampling rate: 2 GSa/s Memory depth: 28 MB Waveform acquisition rate: 110,000 wfms/s You may also upgrade the functional characteristics of the oscilloscope using additional options: a single-channel 25 MHz waveform generator a data transfer protocol decoder an 8-channel logic signal analyzer and a power analysis module. It is very convenient that each channel has its own pair of rotary switches, as well as functional buttons The back panel houses the following connectors: external synchronization output, Pass/Fail output, LAN and USB connectors. Here you may also find the Kensington lock, power input and a cooler. The accessories are shipped in a carton. The package includes: a CD with software and documents, short guide, a set of 4 measuring probes, dual-channel models have two probes, a USB cable, a power cable. To compare the dimensions of this series to other similar devices let&have a look at Siglent SDS2000 and Siglent SDS1000. SDS2000 is more narrow and at the same time significantly higher... and a little bit wider. The device is characterized by a high quality of manufacturing and excellent ergonomics as all Siglent oscilloscopes. Parameters control for each channel are intuitive and do not require learning. This also relates to changing the trigger level and...
