Calculating Impedance in Altium Designer 20

Аватар автора
Алгоритмические аристократы
This video covers how to calculate impedance in Altium Designer. This is especially important when dealing with high-speed designs. You want to make sure impedance is matched to avoid any reflections and maintain good signal integrity. ============================================ PCB GraphTech Vietnam Co.,ltd 5th Floor, VMG Building, 96-98 Dao Duy Anh, Ward 9, Phu Nhuan Dist., HCMC, Vietnam Phone: (84 28) 6292 1170
