Kyocera Taskalfa- 4002i/5002i/6002i Error Code - C1000 || Kyocera Taskalfa Machine failure - C1000

Аватар автора
Инновационный Горизонт
Kyocera Taskalfa- 4002i/5002i/6002i Error Code - C1000 Kyocera Taskalfa Machine failure - C1000 CODE: C1000 Description: MP lift motor error Causes: 1. The MP position switch does not turn on within 1850ms when rotating the MP lift motor in the descend direction.2. The MP position switch does not turn off within 1600ms when rotating the MP lift motor in the ascend direction. Remedy: 1 Checking the MP bottom plate The MP bottom plate does not operate properly. If the MP bottom plate of the MP tray does not move vertically, fix or replace the lift base. 2 Checking the lift lever The lift lever is not properly attached. Check if the lift lever is vertically shifted by the lift motor cam, or if it has the excessive load. Then, reattach the MP tray. Then, replace the MP tray if it is not fixed. 3 Checking the drive gear The drive gear does not rotate properly. Check if the MP bottom plate lift-up drive gears rotate smoothly or have no excessive load. And apply the grease to the frictional parts and fix the related parts so that they can rotate smoothly. 4 Checking the wire The wire is not properly connected. Reinsert the following wire connectors, and replace the wires when they have no continuity.• MP position switch — Relay connector — Feed drive PWB • Feed drive PWB — Engine PWB Electrical Diagram of PWBs 5 Replacing the MP lift motor The MP lift motor does not operate properly. Replace the MP lift motor. 6 Checking the MP positioning switch The MP positioning switch is not...
