Nespresso Vertuo Next type GDV1 repair and full disassembly

This is a complete re-assembly of a Nespresso Vertuo Next coffee machine that I boldly took-it from a recycle bin. At first try the pod was spinning but no water was pumped, followed by some error code. I believed it was the water pump so I decided to completely disassembly, since it was quite dirty. Often, because there is no cleaning cycle run for a long time, this machine will develop a clog in the draining tube ( the black silicone Y shaped tube inside), this causing the coffee waste to overflow inside the machine. That is how I damaged my original machine, rinsing and cleaning the residues without disassembly. This was causing the water to go to the main PCB, that had no conformal coating to protect from water spill, a short developed, the pod spin was destroyed. This machine was a perfect donor for the main PCB I needed but finally I chose to completely clean-it and restore-it. I trashed away the one with the damaged PCB and took care this time to fully cover all the open PCB inside the machine with conformal coating, this time should not be sensitive to any spill.
