BIMDeX AUTOCAD PLANT 3D TO REVIT Exporter

Аватар автора
Современное искусство AutoCAD
AutoCAD Plant 3D to Revit data Exporter/Converter is a simple way of data exchange through plug-in/add-on tool which creates native Revit Families (.rfa) and projects (.rvt) from Auto CAD Plant 3D models (.dwg), along with the metadata and categories. 1. Export your Plant 3D model (.dwg) as a BXF file using our Plant 3D Exporter plugin. 2. The Exported BXF file contains all the design data information along with the model properties/metadata. 3. Import the BXF file inside Revit using the Revit Importer Plugin to obtain native Revit Projects (.rvt) and families (.rfa). 4. BIMDeX automatically categorizes the Plant 3D components such as Pipes, Pipe Fittings, Pipe Accessories, Equipments, Structural Elements, etc. which are mapped to their corresponding categories in Revit. 5. BIMDeX plugin also provides a lot of other customizable options for the user during Export & Import, to obtain the desirable output. Supported Languages: English, Spanish, French, German, Italian Supported Versions: Revit: 2018 - 2022 AutoCAD Plant 3D: 2018 - 2022
