Leigh D4R Pro Dovetail Jig Box Joints

In a class of its own, with a full 24" capacity, the Leigh D4R Pro can produce; through dovetails, half-blind, end to end and sliding dovetails with infinite adjustment of pins and tail widths. Now with the added bonus of being able to produce single pass half-blind dovetails plus two sizes of box joints straight out of the box. A precision one-piece extruded aluminium body, with non-marring textured clamping surfaces and machined-in side stops adds extra rigidity and accuracy. The D4R Pro, produces joints with that classic hand-cut look. The jig is supplied with three robust 8mm diameter shank cutters for chatter free routing. Included with the jig is the e7 eliptical guide bush which fits directly onto many popular routers; some routers may require a different guide bush and or adaptor. The very full specification includes: 8° and 14° dovetail cutters, 5/16" diameter straight cutter, comprehensive user guide, instructional DVD, cam action material clamps, guide bars for cutting sliding dovetails and mounting hardware. Please note: Leigh dovetail jig design is based on the imperial system of measurement but adjustment scales are available in either metric or imperial versions, the metric scales showing imperial equivalents,12.7mm, 9.5mm etc. For a more in depth look at these great jigs and how they work, view the comprehensive user manual from our download link. N.B. The addition of an adaptor for threaded guide bushes will be necessary for most UK routers. To...
