Eurolite PSL-500 showlaser RGB 500 mW

Аватар автора
Экспериментальный путь к благополучию
High-power laser - Laser with the classification 4 - RGB-color-mixture - Operation: ILDA, DMX512, auto, sound-active - Effects: layers, grids, tunnels, waves, writing, graphics, animation - Laser diode: 635 nm red, 532 nm green, 473 nm blue - For DMX-operation on the rear panel: X and Y size adjustment, white balance - Laser safety by integrated scan control, interlock with mechanic shutter, key switch for locking startup - Read user manual before use. Laser installation, alignment and operation only by qualified and trained personell! Never open the housing! Technical specifications Power supply: 230 V AC, 50 Hz ~ Power consumption: 100 W DMX control channels: 11 DMX512 connection: 3-pin XLR ILDA-connection: 25-pin SUB-D Maximum optical power: 500 mW Laser classification: 4 Wavelength: 635/532/473 nm Laser-modules: Red 300 mW, green 150 mW, blue 100 mW Beam: approx. 4 mm / 1 mrad Galvos: max. ILDA 24K Scanning speed: 30000 pps Dimensions without bracket (LxWxH): 600 x 400 x 240 mm Weight: 15 kg
