Generator operator training | How to configure dse 7320 controller from front panel without laptop ACCESSING THE FRONT PANEL CONFIGURATION EDITOR • Ensure the engine is at rest and the module is in STOP mode by pressing the Stop/Reset button. • Press the Stop/Reset and Info buttons simultaneously. • If a module security PIN has been set, the PIN number request is then shown : • Press , the first ‘changes to ‘0’. Press (up) or (down) to adjust it to the correct value. • Press (right) when the first digit is correctly entered. The digit you have just entered will now show ‘for security. • Repeat this process for the other digits of the PIN number. You can press (left) if you need to move back to adjust one of the previous digits. • When is pressed after editing the final PIN digit, the PIN is checked for validity. If the number is not correct, you must re-enter the PIN. • If the PIN has been successfully entered (or the module PIN has not been enabled), the editor is displayed : EDITING A PARAMETER • Enter the editor as described above. • Press the left or right buttons to cycle to the section you wish to view/change. • Press the up or down buttons to select the parameter you wish to view/change within the currently selected section. • To edit the parameter, press to enter edit mode. The parameter begins to flash to indicate that you are editing the value. • Press the up or down buttons to change the parameter to the required value. • Press to save the value. The parameter...
