Tannoy Westminster Royal GR

Аватар автора
Техника и современные устройства
Specifications Performance Compatible Amp: 50-225 Watts Cont power handling: 135W RMS Freq response: 18Hz-22kHz (-6dB) Sensitivity: 99dB (2.83V @1m) Nominal impedance: 8 Ohms Drive Units Type: Dual Concentric HF: 51mm (2") aluminium alloy dome Alnico magnet/Pepperpot Waveguide LF: 380mm (15") treated paper pulp cone Surround: HE twin roll fabric surround Voice Coil: 52mm (2") round wire wound Dispersion: 90 degrees conical Crossover Freq: 200Hz/1kHz (acoustic/electric) Type: Bi-wired, hard wired passive LF: low loss compensated 2nd order HF: 2nd order compensated high freq Shelving Adj: +/-3dB (1kHz-22kHz) Slope Adj: +2/-6dB p/octave (5-22kHz) Construction Enclosure: Compound horn Finish: Walnut veneer Detail: Solid walnut edging and trim Volume: 530L (18.7 cubic ft) Dimensions (HWD): 1395 x 980 x 560mm Weight: 138kg (304 lbs)
