Shimano Nexus 3 Speed Adjustment | Internal-Gear Hub Bike Shifter Adjustment

Аватар автора
I show you how you can adjust the Shimano Nexus 3 speed Internal-Gear Hub Bike Shifter easily. The problem on this bike was that it was jumping gears and going to the third gear although the shifter was set to second gear. Steps for adjusting: 1) Set the shifter to the middle gear (second gear) 2) open the lug nut on the shifter with a 10mm key 3) turn the barrel roller (turn with pliers if tight) 4) adjust until you have the yellow dot between the white lines 5) close the lug nut again - DONE If you have trouble getting the yellow line into position perhaps the shifter unit is out of place like in my case so I also show you how you can take the shifter unit off and position it correctly. TIMESTAMPS: 00:20 Identifying the Shimano Nexus 3 gear shifter 00:31 Explanation of the problem 00:53 Explaining how to adjust the shifter unit 01:36 loosening the lug nut on the shifter and adjusting the barrel roller 02:09 Repositioning the shifter unit by taking it off and placing it back on again 03:32 Final adjustment of shifter unit with barrel roller
