AM20717 Horn 100TSR CNC Tube Bender Sample Bends

Horn Machine Tools CNC 3-axis heavy duty tube bending machine Model: CNC100TSR Maximum Bending Capacity (per mfg. Literature): Round tube (mild steel): 4.00" OD x .217" WT Round tube (non-ferrous): 4.00" OD x .394" WT Round tube (stainless): 4.00" OD x .118" WT Square tube (mild steel): 2.75" OD x .217" WT Solid bar (mild steel): 2.00" OD Maximum degree of bend: 180° + springback Bending rotation: right-hand (clockwise) BendPro G2 CNC Operator Control - Touchscreen - Windows Based Electric servo driven collet (B-axis) Hydraulic driven bend-arm (C-axis) Electric servo driven carriage (Y-axis) Hydraulic clamp Hydraulic pressure die Hydraulic pressure die assist Hydraulic mandrel Automatic mandrel lubrication Automotive tube support Single stack tooling Stock Number: AM20717 Brand: Horn Machine Tools Capacity: 4 inches
