Juniper 04 Настройка VLAN, RVI

Аватар автора
Network is reachable
Настройка на коммутаторах Juniper VLAN (порты trunk и access), создание VLAN интерфейсов RVI, InterVLANrouting Тема 18. Inter VLAN routing. Межсегментная маршрутизация. Утилита Traceroute. Домашняя работа PacketTracer 6. InterVLAN routing (Тема 18 лекций). Курс Huawei HCIA Datacom. Лекция 15. Маршрутизация между VLAN. //L3 set vlans VLAN_101 vlan-id 101 set vlans VLAN_101 l3-interface vlan.101 set vlans VLAN_102 vlan-id 102 set vlans VLAN_102 l3-interface vlan.102 set vlans VLAN_103 vlan-id 103 set vlans VLAN_103 l3-interface vlan.103 set vlans VLAN_109 vlan-id 109 set vlans VLAN_109 l3-interface vlan.109 set interfaces vlan unit 101 family inet address 10.10.1.1/24 set interfaces vlan unit 102 family inet address 10.10.2.1/24 set interfaces vlan unit 103 family inet address 10.10.3.1/24 set interfaces vlan unit 109 family inet address 10.10.0.1/24 set interfaces ge-0/1/0 unit 0 family ethernet-switching port-mode trunk set interfaces ge-0/1/0 unit 0 family ethernet-switching vlan members 101-103 set interfaces ge-0/1/0 unit 0 family ethernet-switching vlan members 109 set interfaces ge-0/1/1 disable set interfaces ge-0/1/1 unit 0 family ethernet-switching port-mode trunk set interfaces ge-0/1/1 unit 0 family ethernet-switching vlan members 101-103 set interfaces ge-0/1/1 unit 0 family ethernet-switching vlan members 109 set interfaces ge-0/1/3 unit 0 family ethernet-switching port-mode trunk set interfaces ge-0/1/3 unit 0 family ethernet-switching vlan members 101-103...
