Mitutoyo 543-287B Absolute Digimatic Indicator ID-C Calculation Type

Mitutoyo 543-287B Absolute Digimatic Indicator ID-C Calculation Type; .5"/ 12.7mm Range , 3/8" Stem The Mitutoyo 543-287B Absolute Digimatic Indicator ID-C is a conventional indicator that simply displays a spindle displacement but due to the Calculation Type Feature it incorporates an internal calculation function in place of spindle displacement. With features, measurements such as feeler, inside diameter and radius of curvature measurement can easily be obtained without the hassle of conversion tables or equivalents. It performs internal calculations using the formula Ax+B+C (assuming spindle displacement as x) while the specified coefficients A, B and C can be set with respect to the purpose of measurement or dimensions of the fixtures. This unique feature allow you to read your measurements directly, without fumbling for conversions. This model has a measuring range of .5"/ 12.7mm with a 3/8" Stem diameter and .00001"-.05"/0.0002-1mm switchable Resolution. Features: SPC data output Switchable Resolution Inch/Metric conversion Calculation-Type to directly read measurements without conversion tables Call: 864-433-9771 & tell them you saw it online and you want the indicator with fixture.
