Sri Balaji Audio world Thoothukudi 9994690102 SERVICE MANUAL This system incorporates Dolby* Digital, Dolby Pro  Logic (II) adaptive matrix surround decoder, and the  DTS** Digital Surround System. * Manufactured under license from Dolby  Laboratories. “Dolby”, “Pro Logic” and the double-D symbol are  trademarks of Dolby Laboratories. ** Manufactured under license from Digital Theater  Systems, Inc. “DTS” and “DTS Digital Surround”  are registered trademarks of Digital Theater  Systems, Inc. US and foreign patents licensed from Dolby  Laboratories. DVD DECK RECEIVER AEP Model UK Model E Model Australian Model CX-BK7 Ver 1.2  2004.09 9-961-333-03 Sony Corporation 2004I05-1 Personal Audio Company C  2004.09 Published by Sony Engineering Corporation SPECIFICATIONS • CX-BK7 is the amplifier, disc player, tape deck and tuner section in BMZ-K7D. Amplifier section The following measured at AC 120, 127, 220, 240 V,   50/60 Hz Rated Power Output at Stereo mode Continuous RMS power output (reference) Front speaker: 150 + 150 watts (6 ohms at 1 kHz, 10%  THD) Center speaker: 50 watts (8 ohms at 1 kHz,  10% THD) Surround speaker: 50 watts (8 ohms at 1 kHz,  10% THD)  Inputs LINE IN AUDIO (phono jacks): voltage 1.1V, impedance  47 kilohms LINE IN VIDEO (phono jack): max. input level 1Vp-p,  unbalanced, Sync  negative, impedance  75 ohms MD (AUX) IN (phono jacks): voltage 1.1V, impedance  47 kilohms    MIC (phone jack): sensitivity 1 mV, ...
