RIGOL MSO2072A Logic analyzer Pattern Trigger mistriggers explanation!?

Аватар автора
Игровые Войны и Баталии
I have my MSO2072A Logic analyzer connected to an FPGA controlling 4x 7 segment display and tried to trigger with the pattern trigger But the pattern I want to trigger on also triggers other patterns. In this video I try to explain why I think this happens. Sorry for the long video and my bad english, this is my first video.
