TRUMPF Trumatic 500 - Punching Machine

The Trumpf Trumatic 500 is completed with the pallet changer system ´Sheetmaster´ connected with the drain table ´Trumagrip´. Machine with frequent maintenance and all the documents in order. Brand: TRUMPF Model: Trumatic 500 Type: Punching Year: 1997 Made in Germany Technical specifications: Control Unit: Trumagraph CC 220 S (Bosch) X-axis: 2535 mm Y-axis: 1280 mm Max. Punching force: 220 kN Max. Sheet thickness: 8 mm Max. workpiece weight: 230 kg Max. punching diameter: 76.2 mm Max. positioning speed parallel X-axis: 90 m/min Y-axis: 60 m/min C-axis rotation: 360°/s fully rotating Punching head: Hydraulic drive Automatic tool changer: 18 tools with 2 clamps No. of tools if using Multitool: up to 18 tools with 2 clamps Bar Capacity: 50 mm Spindle Speed: 57 - 4200 RPM Spindle Motor: 15 HP Turret Type: 12 Position Turret Dimensions: Length: 6900 mm Width: 5800 mm Height: 2200 mm Weight: 1100 kg Dimensions Sheetmaster + Trumagrip: Length: 3800 mm Width: 2400 mm Height: 1900 mm Weight: 1800 kg Extras included: Tool holders Sheetmaster (pallet changer system) Truma grip (drain table) Books and documents of revisions and maintenances For more information, please contact us:
