ANT 7s-16s BMS basic tutorial setup for 13s battery

Timestamps 00:00 13s wiring for 7s-16s ANT BMS 00:10 connect B- wire and black balance lead to cell negative 00:25 next attach white wires to cells positive terminal in order shown 00:37 for 13s configuration, ignore the last two white wires on the first harness 00:56 on the cell, you will connect two balance wires. 1:11 the second harness red wire and first white wire next to it are connected to the positive terminal 1:34 attach all the wires in order shown, with the last wire going to cell positive terminal 2:00 plug in both balance wire harnesses 2:19 plug in the wire connector with tiny red and black wire 2:24 using a 3-5v voltage source (such as a battery) momentarily connect black to negative and red to positive 3:42 if you hear a beep and see a tiny flashing light, the BMS Bluetooth is on and ready to connect 4:22 download the ANT BMS iOS app from the store 4:42 Open the ANT app 4:48 showing weird voltages because its set for 16s 4:56 click “parameters” at the bottom 5:03 click FastSettings 5:24 enter 12345678 as password 5:51 select battery chemistry so it presets all values for that type of 5:56 enter number of series for your battery and wiring 6:05 enter AH (AH per cell x number of cells in PARALLEL) in this case its 5ah x 1 cell = 5ah 6:26 the settings didn’t stick because Bluetooth connection was weak 7:43 reconnected and set 13s 7:58 all 13 series are reading correctly now 8:09 Vparameters (Voltage parameters) all set to default LiFePO4 values during...
