HP LASERJET 5200 PAPER JAM GANTI (FUSER FILM)

Fuser Removal Remove the Rear Door and Rear output bin. Facing the back of the printer, remove the two machine screws (callout 1) holding the Fuser in the chassis. Using a small, flat bladed screw driver, lift to disengage the Fuser Assembly detents (callout 2). Grasp the green Pressure Release Handles (callout 3) and pull the Fuser out of the chassis. HP LaserJet 5200 fuser removal Market Point now provides service manuals so I’m just going to point you in that direction for the main drive assembly removal. It’s pretty easy. I just replaced one the other day and it took less the half an hour. Go to page 166 of the service manual here Note : Because of a recent mishap I learned that the main drive assembly gears and frame are identical in the 5000 and 5100, so those parts are interchangeable. However, they do take different motors. I had someone accidentally purchase a 5200 gear assembly and I put it into a 5200. Everything worked ok until I went to print. Printing using the bypass tray worked fine because it prints at a slower speed. Printing through the feed trays was another story! At normal operating speed the slow motor caused paper jams using 11 X 17 paper and caused 41.1 incorrect paper size errors with letter sized paper. Additionally, the print size was reduced on the paper because of the slow speed. Once I swapped motors the machine was working again. So, when in a pinch you can order and replace one or the other main drive gear assemblies, just make sure you...
