EEVblog 1583 - Advanced Oscilloscope Triggering: Glitch/Pulse/Runt/Interval

A practical demonstration on how to use advanced oscillocope trigger features to trigger on an unsyncronised infrequenct runt/glitch pulse. Includes Pulse/Glitch, Runt, Interval, Zone triggering, and infinite persistence display, and waveform update speed demonstrated and explained. Using the Rohde & Schwarz MXO4, Siglent SDS2154X HD, Keysight 3000T, Tektronix Series 2, and the Rigol DHO800. 00:00 - Advanced oscilloscope triggering features 00:27 - The test glitch signal 01:25 - Infinite persistence mode is your first tool 02:33 - How to estimate how often you can cature this 04:39 - DaveCAD drawing of how capture windows work 05:45 - This is NOT about trigger level 06:53 - Demonstration of using Glitch/Pulse capture on the MXO4 09:46 - This glitch is actually a Runt pulse 11:31 - Can you use History mode? Yeah, but good luck... 12:47 - Interval Trigger Mode on the MXO4 13:37 - Check this out! We found another hidden glitch pulse 14:23 - Siglent SDS2354X HD 16:14 - You don&need an expensive scope! The Rigol DHO800 17:34 - Keysight 3000T 17:47 - This is a non-synchronous free running organic glitch 18:36 - Tektronix 2 Series 18:57 - Can you use Zone Triggering? Yeah, nah. Or with crypto: BTC: 33BsprBQNBtHuVzVwDmqWkpDjYnCouwASM ETH: 0x68114e40ff4dcdd384750500501e20acf3875f8c BCH: 35n9KBPw9T7M3NGzpS3t4nUYEf9HbRmkm4 USDC: 0x68114e40ff4dcdd384750500501e20acf3875f8c LTC: MJfK57ujxy55su4XicVGQc9wcEJf6mAoXF Other channels: #Tutorial Теги: eevblog,video
