AMF - Zero Point System working principle

Absolutely insensitive to lateral and pull forces that arise. Precision ground support surfaces made of hardened stainless steel for planeparallel clamping ≤ 0.005 mm. 2 Hardened piston - the combination of form fit and self-locking results in reliable and constant clamping. 3 Precision balls for optimal power transmission as well as vibration-inhibiting and wearresistant use. 4 Ball support made of stainless steel seals the clamping module against dirt and liquids.. 5 Robust plate springs for maximum pull-in, closing and holding forces. 6 Module floor with integrated air jet function. A The low installation depth of the clamping modules of 22 mm permits a height of the base plate of only 28 mm (without blow out, only 24 mm).
