Road Marking Machine STiM Shmel 11A

Group of companies STiM Tel./fax: + 375 (162) 50-82-50. e-mail: contact@stim.by Katin Bor, 103, 224025, Brest, Belarus The Shmel 11A road marking machine is designed for airless horizontal road marking using quick-drying paints using retroreflective glass beads. " Shmel 11A " is the most popular road marking machine in the CIS countries. The machine has a relatively small size and high maneuverability, thanks to which it is perfectly suitable for marking not only for main roads, but also for city streets. Main technical specifications: - engine (Briggs & Stratton) with maximum power: 23 hp (17 kW); - engine fuel type: AI-92; - inlet compressor capacity (Fini): 380 l / min; - conditional performance of the paint pump (Graco): 26 l / min; - application speed of a single solid line (width 15 cm, 800 g / m2): 10.8 km / h; - application speed of a double solid line (width 15 cm, 800 g / m2): 5.5 km / h; - maximum marking speed: 12 km / h; - maximum working paint pressure: 130 bar; - capacity of the capacity for the paint: not more than 600 kg; - capacity of a container for glass beads: no more than 240 kg; - overall dimensions of the machine in working position (length / width / height), no more, m: 7.9 x 2.8 x 2.9; - overall dimensions of the machine in transport position (length / width / height), m: 5.5 x 2.1 x 2.8; - curb weight of the machine: 2660 kg; - gross vehicle weight: 3500 kg. Basic equipment of the machine: - a marking block on the left side of...
