SANSUI AU-D607X Decade

Японский усилитель SANSUI AU-D607X Decade. Год выпуска аппарата 1985. Стоимость на момент производства составляла 79,800 йен. Спецификация: Model : Integrated DC amplifier *Power amplifier section* (10Hz ~ 20kHz, both ch driven) Effective output 105W +105 W (6Ω) 90W +90 W (8Ω) Total harmonic distortion (10Hz ~ 20kHz) (8Ω, at the time of an effective output) 0.003% (6Ω, 1/2 at the time of an effective output) 0.005% Intermodulation distortion (60Hz: 7kHz = 4:1) (8Ω, at the time of an effective output) 0.003% (IHF, both ch behavior, THD0.03%) output bandwidth 5Hz ~ 70kHz Dumping factor (new IHF, 20Hz ~ 20kHz) 80 (6Ω) Frequency characteristic (1W) DC ~ 300kHz +0-3dB Slew rate ± 180V/μsec (6Ω) Rise time 0.6μsec *Equalizer amplifier part* Input sensitivity / input impedance (1kHz) Phono MM: 2.5mV/47kΩ Phono High MC: 2.5mV/100Ω Phono MC: 300μV/100Ω CD, Tuner, Tape1, 2/PCM: 150mV/47kΩ (1kHz, THD 0.01%) Phono maximum permissible input MM: 300mV High MC: 300mV MC High: 30mV (A network, a short circuit) SN ratio Phono MM: 88dB Phono MC: 70dB CD, Tuner, Tape: 110dB Tone control Bass: ± 10dB (50Hz) Treble: ± 10dB (10kHz) Subsonic Filter 16Hz (-3dB, 6dB/oct) Muting -20dB *General* Rated power consumption (Electrical Appliance and Material Control Law): 230W External dimensions: 161 x 431x 466 mm Weight: 15.0kg В ролике звучит: Yello - Touch Yello (2009)
