Teardown of New Samsung 45W GaN Charger EP-T4510 (For Samsung S22 Series)

If you wanna buy the tester of POWER-Z, you can visit our Amazon store: Introduction --------------------------------------------------------------- Hi, guys. Welcome back to today&video. We published an unboxing & compatibility test video of Samsung S22+. There is no charger in the box. But Samsung released an additional 45W charger, which is also the first GaN charger made by Samsung. So, let&take a look at what&inside. Bill of materials (BOM) ------------------------------------------ Input Fuse: Better Electronics Rectifier Bridge: RYBS4010 Capacitor: CapXon Master Control Chip: Dialog iW9801 GaN IC: Navitas NV6014 Optocoupler: CT1018 Protocol Chip: Dialog iW709 Synchronous Rectifier: POTENS PDC85N11X-5 Output VBUS MOSFET: Winning Team SFTN7422SMP Chapter ---------------------------------- 0:00 Intro 0:36 Unboxing 1:21 Testing 2:05 Teardown 3:09 Analysis 5:31 Summary For more details. You can visit our website: SOCIALS:
