Developing Embedded GUI with SquareLine Studio [2/2]

*ESP32-S3 GPS Speedometer with BN-880Q* In the previous video, we finished the basic hardware configuration with the ESP32-S3-based WT32-SC01 PLUS and BN-880Q GPS module. This video explains in detail how to complete an embedded GUI using Square Line Studio. After working on the UI through SquareLineStudio, you can export it as a c-type code. You can take this and add it to your source code to complete the overall screen configuration. Even in resource-poor MCUs, we can create very good graphics. If you need an embedded GUI, I think this will be very important. *Timestamps 0:00 - Developing Embedded GUI 1:26 - MCU Application Design 2:59 - SquareLine Studio Tutorial 25:00 - Using Exported UI Code 29:56 - Outro: The future of embedded GUIs? [Let&build a GPS Speedometer with ESP32-S3 and BN-880Q(GPS, Compass) [1/2]] [How good is it? "WT32-SC01 Plus" with ESP32-S3!] [SquareLine Studio] [WT32-SC01 Plus] [BN-880Q] [MX 1.25mm Male Female Connector Kit] [Project GitHub] *OLD GPS Project with NodeMCU* [Part 1. NodeMCU(ESP8266) | GPS | ILI9488 - Showing the Latitude and Longitude on Display] [Part 2. NodeMCU(ESP8266) | GPS | ILI9488 - Showing Google Map with Device Position on Display?️] [Part 3. NodeMCU(ESP8266) | GPS | CSV Data Logging - GPS Tracker (feat. GPS Visualizer)?️] #ThatProject
