HAPPYMODEL ExpressLRS FPV ELRS ES900TX ES900RX 915MHz/868MHz Long Range Module for Radiomaster TX16

HAPPYMODEL ExpressLRS FPV ELRS ES900TX ES900RX 915MHz/868MHz Long Range Module for Radiomaster TX16S Micro Mini fpv Drone parts ES915RX(Discontinued) ES900 RX ES915TX(Discontinued) ES900TX MCU STM32F103RBH6 ESP8285 STM32F103C8T6 ESP32+ESP8285 RF Chip SX1276IMLTRT SX1276IMLTRT SX1276IMLTRT SX1276IMLTRT Antenna plug IPEX4 IPEX1 SMA SMA Dimension 16mm*10mm*3mm 12mm*12mm*3mm 55mm*39mm*13mm 55mm*39mm*11mm Weight 0.7g 0.6g / / Firmware upload Betaflight pass-through Betaflight pass-through or Wifi SD-card or Configurator Wifi or Configurator Item: ExpressLRS ES900TX ES900RX 915MHz Long Range Module Parameters: ES900TX: MCU:ESP32+ESP8285 Dimension: 55mm*39mm*11mm Weight: 9.2gram (only the TX module) Antenna connector: SMA VCC input: 5~13v, Recommend 5v~9v RF Frequency optional: 915mhz or 868mhz(EU) Maximum Output Power: 33dBm(For 27dBm operation, we recommend add a fan for force cooling) Wifi update firmware function for ES900TX would be available in a short time.
