HONDA CB1000R MANUAL STEERING FRONT

Before assembly, wash all parts with a high flash or non-flammable solvent and wipe them dry. When installing the fork dust seal and the oil seal, wrap the edge and groove of the fork pipe with a tape. Apply fork fluid to new dust seal lips and new oil seal lips. Install the dust seal, stopper ring and oil seal. ! Install the oil seal with its marked side facing toward the axle holder. Install the back-up ring, slider bushing and a new fork pipe bushing. ! Remove the burrs from the slider bushing mating surface, being careful not to peel off the coating. Install the fork pipe into the fork slider. Drive the oil seal in using the special tools. TOOL: Fork seal driver 07YMD-MCF0100 Install the stopper ring into the fork slider groove securely. ! Do not scratch the fork pipe sliding surface. Install the dust seal into the fork slider securely. Install the fork damper into the fork pipe. Apply a locking agent to the fork socket bolt...
