PNP 2N3906 Bipolar Junction Transistor BJT demonstration electronics circuit

Аватар автора
Mad Scientist Mischief
PNP bipolar junction transistor is controlled by base current just like the NPN BJT does but power polarities are opposite. A couple LEDs, one at the base and one at the collector, help give an idea of how much current is flowing by how bright they get. #electronics
