How to replace LCD Screen on Lenovo IdeaPad Gaming 3 15IMH05. Step-by-step instructions

Аватар автора
Чистый дом - счастливое жилье
This is a Lenovo IdeaPad Gaming 3 15IMH05 screen replacement guide. For the replacement process we’ll need the following tools: -Heat Gun -Plastic picks To begin turn the laptop off by pressing and holding the power button. Start removing the bezel. Start from the left side then using both hands go around the perimeter unsnapping the tabs underneath. Put the bezel aside. The LCD screen is glued to the plastic cover. We need a Heat Gun to soften the glue. Warm up right and left sides of the top cover. Using plastic pick start gently separating the LCD screen. Use the Heat Gun repeatedly on both sides to make sure the glue is soft. Separate the LCD screen and place it on the keyboard. Use a plastic pick to open the connector’s bracket. Disconnect the video cable. Discard the old screen. Take the new LCD screen and place it on the keyboard. Reconnect the video connector. Close the connector’s bracket. CAUTION! It is very important not to force any connectors. As well...
