focal point adjustment（laser head dimming)Raytools head

raytools laser head BM110 BM111 is equipped with automated focusing system,it still need dot manually tore-determine the focus position when users replace the lens or lasers. For details about operatingsystem parameters, please refer to the system instructions. Manual dotting can refer to the following steps: 1. The laser head scale is displayed to the maximum, and the laser power range is set to80-100w; 2. Then, within each moving 0.5mm (as small as possible), activate the laser to make a hole inthe textured paper; 3. Dotting several times, finally compare and find out the scale corresponding to the smallesthole, which is the zero focus position, that is, the focus spot is just at the end of the nozzle end face. if its focal point is not finished adjustment. its working efficiency is bad cuts very rough. So being user we must adjust its focal point first. welcome visit our website
