[Tutorial] Extract Google Earth 3D models with Pix4D and PV*SOL premium 2018

1. Create screenshots in Google Earth Pro 2. Photogrammetry with Pix4D 3. Import of the 3D model into PV*SOL premium First, start Google Earth Pro. For this video I chose a free-standing, relatively complex building in England. Here I enter the coordinates of the object. A 3D model is to be extracted from this object. First, I determine the size of an edge of the model. This is later used in PV*SOL to reproduce the scale. To do this I use the ruler function of Google Earth and draw a 3D path to an edge that is well visible. The measured length of the edge is approx. 20m. In the next step I will take about 30 - 40 screenshots of the scene to create a 3D model in Pix4D. In order to achieve an optimal result with photogrammetry, all labels and menus should be hidden first. Now the screenshots can be made. Recommendation: take pictures at 3 different altitudes: - 12 pictures at the height of the ridge or the highest point of the building. - 8 pictures from different angles of the...
