JBL Clip 2 battery replacement ; teardown ; disassembly

Аватар автора
Умный Технолог
Click "Show more" to see the entire description. 0:17 Step 1 - Remove the speaker cover 0:27 Step 2 - Loosen these screws and open the amplifier 0:49 Step 3 - Desolder these pins 1:05 Step 4 - Loose these screws 1:13 Step 5 - Lift up the circuit board 1:22 Step 6 - Remove the original battery 1:29 Step 7 - Install the Cameron Sino battery 1:39 Step 8 - Install the circuit board 1:49 Step 9 - Solder these pins 2:06 Step 10 - Plug the amplifier power cord 2:11 Step 11 - Install the amplifier the close the cover This is the battery for Speaker model JBL Clip 2 Battery model: CS-JMC200SL Capacity: 800mAh / 2.96Wh Volts: 3.7V Dimension: 58.80 x 41.70 x 4.20mm Warranty: 12 Months Difficulty: ★★★☆☆ Do you want more video with different devices? Comment us downstairs and tell us which model you want. To know more Cameron Sino. Please follow our social media below!
