2001 (2001-2007) Ford Escape, Mazda Tribute, Mercury Mariner V6 3.0L Starter Motor Replacement

Аватар автора
АвтоСпасатель
How to replace a starter on (2001-2007) Ford Escape, Mazda Tribute, Mercury Mariner V6 3.0L without draining cooling system! 1) Remove Battery Negatve terminal 2) Remove the air-intake hose & air filter housing 3)Pull wiring harness retainer (push-in style) loose, pull heater hoses back 4) Remove 13mm nut positive wire from starter 5) Remove 10mm nut from starter solenoid wire 6) Rmove 13mm mounting bolt from rear of starter; Remove 13mm bolt from front of starter (beneath coolant hose)[wiggle or wobble socket required] 7) Carefully remove starter by bending heater hoses and loosened wire loom out of the way -Reverse procedure to install
