Sintonizador AM/FM Stereo ST-A790. Parte do sistema modular LBT -A595. SONY.

Аватар автора
Современная техника для дома
Demonstrando internamente os componentes básicos do ST-A790. Essa peça faz parte do sistema modular LBT A-595. Esse sintonizador é bem completo e compreende todas as funções necessárias para o sistema. 2 tomadas traseiras, conexão para antena AM e FM. Alimentação de entrada 120V/220-240V. Conexões System Control. Permite a interação com todo o sistema. Componentes: Fonte: LA5667 - Regulador de voltagem múltipla. 13V/350mA e 5,6V/100mA. Sintonizador: LA1835 - Multiplexador. LC7218 - Sintonizador eletrônico. Internally demonstrating the basic components of the ST-A790. This part is part of the LBT-A595 modular system. This tuner is very complete and comprises all the functions necessary for the system. 2 rear sockets 450W maximum, connection for AM and FM antenna. Input power 120V/220-240V. System Control connections. Allows interaction with the entire system. Components: Power supply: LA5667 - Multiple voltage regulator. 13V/350mA and 5.6V/100mA. Tuner: LA1835 - Multiplexer....
