Programming ATV312 for Terminal Start-Stop & 4-20mA Speed Control | Altivar | Schneider Electric

In this comprehensive tutorial, we dive into programming the Altivar 31 & 312 (ATV31/ATV312) Variable Frequency Drives (VFD) for terminal start-stop control and 4-20mA speed regulation. Whether you&a seasoned engineer or just starting in the field, this step-by-step guide will walk you through the process. ➡️ We&cover everything from wiring the 2-wire terminal start/stop control on Logic Input 1 (LI1 + 24vdc) to configuring precise speed control using Analog Input 3 (AI3). Don&miss out on mastering these essential skills for VFD programming. ? Timestamps: 0:01 - Introduction and Setting up Terminal Control 1:28 - Programming for 4-20 mA Reference 2:51 - Summary and Conclusion ? Learn more with Schneider Electric FAQ: --------------------------------------------------------------------------------------------------------------------------------------------------------- ? DISCOVER JOB OPPORTUNITIES...
