ESP32 #2: Soldering the ESP-WROOM-32 to a breakout board (Part 1)

Аватар автора
JavaScript для самообучающихся
Disclaimer: The particular module I was soldering had issues with programming, so it&possible that it was damaged during the soldering shown in this video. Exercise caution when soldering the ESP32 with a soldering iron... This is first of a two part video where I solder the ESP32 module (ESP-WROOM-32) to a breakout board. In this video, we&take a closer look at the ESP32 module&package, and after that I prepare the breakout board for soldering of the ESP32 module by applying flux, and then use regular solder and soldering iron to solder the ESP32 to the board. Along the way, I don&do a good job soldering, so I need to use some wick to correct the solder joints and such.
